Colorimeter Precision Color Meter SCI SCE Color Difference Analyser Color Detection with 8mm Measuring Aperture Observer 2° 10° Optical Geometry 8/d 20000 Groups Data Storage

YFYIQI Colorimeter Precision Color Meter SCI SCE Color Difference Analyser Color Detection with 8mm Measuring Aperture Observer 2° 10° Optical Geometry 8/d 20000 Groups Data Storage Introduction: This high precision colorimeter is developed and produced according to the international standard of CIE and GB. By adopting the latest 8/d optical configuration and equipped with sensor of high sensitivity. It has a high reproducibility and stability. Application: 1. Color matching in industry and quality control in production process. 2. Color-difference detection and color-difference bath control in production process. 3. Color-difference analysis of spray paint surface and electroplate surface. Color-difference of different areas of the metal treating surface. 4. Quality control in color difference in sample and the standard. Color difference inspection of batch products in outdoors. 5.On-line monitoring of color difference in production process. Color analysis testing in other special industry etc. Specification: Optical geometry: 8/d, equipped with SCI and SCE Synchronous test mode Measure caliber: 8MM Observer: 2°& 10° Sensor: Silicon photodiode array System language: Simplified Chinese,Traditional Chinese, English Repeatability: Standard deviation △E﹡ab≤ 0.06( Using the standard whiteboard to measure 30 times and take the average.) Display: Value of chromatism, chromatic value, color space figure, qualified/ unqualified determination color analysis Observing light source: D65 D50 C A F2 F8 F11 Color space figure: L* a* b、L* c* h、Yxy、RGB Color difference formula:△E* ab、△E* ch Power source: Special 3200 mAh large-capacity lithium battery, AC adapter Data storage: 20000 groups Dimension: 196×71×93(L×W× H) Weight: 660g(including the calibration boards) Connection: USB Standard accessories:White/black calibration board, USB connection wire,Φ8MM objection cover,power source adapter,Li-battery, color software

• Repeatability: Standard deviation △E﹡ab≤ 0.06( Using the standard whiteboard to measure 30 times and take the average.); Comply with the international general color detection standard which will ful- fill the demand of different industries.
• Observing light source: D65 D50 C A F2 F8 F11; The latest design with small-caliber can measure not only even smaller appearance but also arc-shaped appearance, which has solved the problem that other domestic instruments can not measure the irregular appearance.
• Color difference formula:△E* ab、△E* ch; 3200mAh Li-battery with large capacity ensures more convenient and reliable operation for long time measurement.
• Measure caliber: 8MM; Optical geometry: 8/d, equipped with SCI and SCE Synchronous test mode; Professional streamline design which will better suit the body mechanics, it also makes the instrument look more high-end and easier to operate.
• Do not use the instrument in areas where dust, smoke, corrosive gases into the instrument inside, it may cause the damage of instrument;Do not use the instrument near equipment which produces a strong magnetic field, it would cause data exception of instrument.
