5 Million Pixels Electronic Eyepiece USB2.0,40-640X Monocular Electron Biological Microscope,Image Processing Software

KP-PH35S5000 Optical enlargement:40X-640X Observation tube:Monocular tilted 45 degrees,360 degrees of rotation Eyepiece:WF10X/18mm,huygens 16X Objective lens:Achromatic lens,4x,10x,40x (spring) Converter:Three holes conversion Operating platform:Double mechanical mobile platform,size 115mm*125mm,Moving range 74mm*30MM Focusing mechanism:Coarse micro coaxial,coarse 20mm,fine-tuning of 1.3mm Condenser:Abbe concentrator,N.A.=1.25, with variable aperture Light source:LED cold light source,high brightness rechargeable adjustable brightness Power:External regulated power adapter,DC5V/2A Packaging:Bubble+carton Sensor:5.0M/Aptina(C) Sensor Size:1/2.5"(5.70x4.28) Resolution:2592x1944 5 million pixels Pixel Size:2.2μmx2.2μm G Sensitivity Dynamic Range:0.31v/lux-sec 65.2dB Frame Rate:2@2592x1944,3@2048x1536,5@1600x1200 ，7.5@1280x1024 Exposure:0.1ms~2000ms White balance:ROI White Balance/ Manual Temp-Tint Adjustment Capture/Control API:Native C/C++, C#, Directshow, Twain, Labview Recording mode:Image and video Capture/Control API:Native C/C++, C#, Directshow, Twain, Labview Computer Requirements:CPU equals to Intel Core2 2.8GHz or higher Memory:2GB or more, USB2.0 port Packing List : 1、Eyepiece 10X/16 *1 2、Huygens Eyepiece 16X *1 3、Objective lens 4X *1 4、Objective lens 10X *1 5、Objective lens 40X *1 6、Microscope body *1 7、Power adapter *1 8、5MP digital camera *1 9、1.8m USB cable *1 10、CD software *1 Note: 1、We will provide suitable EU Plug, US Plug, UK Plug and Australian Plug according to the country/region where the client is located. 2、Prices quoted on all our products do not include customs duties. 3、This product does not contain a computer.

• 40X-640X Optical enlargement
• Observation tube:Monocular tilted 45 degrees, 360 degrees of rotation
• Eyepiece:WF10X/18mm,huygens 16X
• Objective lens:Achromatic lens,4x,10x,40x(spring)
• Converter:Three holes conversion
